Manage widgets for collecting a Reference

Cargosnap offers multiple ways to collect a Reference for your file. You can manually type a reference or scan a code to start your process in the most efficient way.

The reference as the title of your file

Most customers use the same reference for a file that is also used in their Warehouse Management System (WMS) or Transportation Management System (TMS). This can be an order/shipment number or transportation number.

The "Reference" will be displayed in your file like this:

How to set this up?

To build your own mobile app with multiple reference widgets, navigate to "Teams, Devices and Users", via your company name in the upper right corner.

  • Select the Team which settings you would like to update.
  • Select "default device settings" in the right menu sidebar.
  • Select "Manage Widgets".

Manage the Reference widgets

To build the app, simply select the Top (Reference) widgets from the drop-down menus on the right. You can subsequently drag and drop the blocks, to change the sequence in which these widgets appear in your app. The available options:

  • Barcode/QR code – scan a barcode

  • Container code – scan the ISO compatible code from a container door

  • License plate EU/BR/IN – scan a vehicle (truck or trailer) license plate

  • Text & Number - scan a text and/or number, or simply add it with the keyboard

  • Keyboard – data entry with your keyboard. This field can optionally be checked for the format (e.g. having the exact number of characters you expect)

  • Timestamp - in case there is no specific reference available at the moment, you may use the automatic timestamp mechanism that selects the current date and time.

  • GetFile - Get an existing open file to add additional information to it.

Scherm­afbeelding 2026-11-17 om 12.25.27

In below example you see the mobile app with the:

  • 'Barcode / QR-code' reference as the Top (Reference) Widget.
  • 'Workflows' as the Bottom Widget.

💡Tip: If you press+hold the Top Widget, you can swipe to the left and to the right.

Scherm­afbeelding 2025-12-17 om 16.29.40

Custom titles for your widgets

Change the name of your Top (Reference) Widgets by clicking the 'pencil' in each widget, so that your operators directly understand which information is needed for the file reference. For example:

  • Custom title = Order number
  • Custom helper text = Fill in the order number

Scherm­afbeelding 2025-12-09 om 15.28.46

In the mobile app the 'Barcode / QR-code' Top Widget will look like this:

IMG_9159

Also see this article about "Custom titles for your reference widget".
